Yamaha Pure [OHLINS] – Street/Track Shock Absorber

OHLINS shock absorber for Yamaha Pure

The OHLINS brand shock absorber is specifically designed for use on the road and race track. It is suitable for the Yamaha Pure motorcycle model and offers precise suspension tuning for different driving conditions. The STX model is characterized by its high-quality workmanship and technical features.

Technical features

• Bore size: 46.00mm (1.81")
• Damper method: Hydraulic
• Setting type: Adjustable rebound damping and adjustable spring preload
• Length (extended): 312.00mm (12.29")
• Linear spring rate: 11.72 kg/mm (657.00 lb/in)
• Material: aluminum and steel
• Color/Surface: Chrome plated with yellow accents
• Mounting position: Suitable for front and rear
• Position reservoir: Inside
• Type: Monotube shock absorber with spring sleeve

Function and area of application

The shock absorber works on the hydraulic principle and ensures effective dampening of road shocks. The adjustable rebound damping allows for individual adjustment of the kickback behavior, while the adjustable spring preload allows adaptation to different loads and riding styles. This supports optimal road holding and control in various driving conditions.

Thanks to the use of aluminum and steel, the shock absorber is robust and light at the same time. The chrome-plated surface with yellow details offers an attractive look that matches the design of the motorcycle. The internal position of the reservoir contributes to a compact design and protects the damper components from external influences.

Assembly and use

The product is suitable for both front and rear wheel mounting. It is delivered piece by piece and is part of the SUSPENSION GROUP-REAR product group. Assembly should be carried out in accordance with the vehicle manufacturer's specifications to ensure safe and functional integration.

This shock absorber is a technical component that helps improve driving dynamics and comfort. It is aimed at users who value precise suspension tuning and who travel both on the road and on the racetrack.
