Vespa GTS 125 I-GET Super Notte [2020] - H20 I-Tech cylinder set - Ø63mm Piaggio/Vespa

MALOSSI H20 I-Tech cylinder set with Ø 63 mm

The H20 I-Tech cylinder set is designed for the Vespa GTS 125 I-GET Super Notte from 2020. With a cylinder bore of Ø 63 mm, 58.7 mm stroke and 183 cm³ displacement, it offers a clearly defined technical configuration for competition use.

Cylinder and machining

• Cylinder bore: Ø 63 mm
• Stroke: 58.7mm
• Displacement: 183 cm³
• Compression ratio: 11.48
• Cylinder-piston clearance: 0.05 mm

The cylinder is made of a primary aluminum alloy with a high content of hardened and tempered silicon. Its liner has a silicon carbide coating in an electroplated nickel die. Cross smoothing is done in two diamond passes with very limited tolerances. Machining is carried out on machine tools with high-precision numerical control. Newly calculated heat exchange surfaces support the thermal design of the cylinder.

Pistons and piston rings

The ultra-compact, lightweight and reinforced piston features three rings. It is made from a special aluminum alloy with a high silicon content and low thermal expansion. There is a tin coating on the sliding surfaces. The piston is also machined on numerically controlled machine tools and has improved heat exchange surfaces.

• First ring: compression ring made of nitrided and chrome-plated steel
• Second ring: special cast iron
• Wiper ring: three-piece design made of special chrome-plated steel alloy

The special rings are designed for good sliding properties and very high mechanical resistance.

Vehicle assignment

• Vespa GTS 125 I-GET Super Notte, built in 2020

Factual usage instructions

This product is intended exclusively for use in competitions at designated venues in accordance with the regulations of the relevant sports associations. No liability is assumed for improper use. Product-specific instructions are available.
