SUZUKI DR Z 400 E [2000-2015] - Connecting rod set

HOT RODS connecting rod set for the SUZUKI DR Z 400 E

This connecting rod set from HOT RODS is intended for the 4-stroke engine of the SUZUKI DR Z 400 E from the years 2000 to 2015. It includes the connecting rod and the associated crank pin and crank pin bearing components. This means that the central components of the sentence are available together.

The fully listed dimensions make it easier to clearly select and objectively compare the dimensions. In addition to the distance between the connecting rod eyes, the internal dimensions and widths of the large and small connecting rod ends are given. The length of the crank pin is also shown exactly.

Technical data

• Engine type: 4-stroke
• Inner diameter of the large connecting rod end: 43 mm
• Width of large connecting rod end: 21,800 mm
• Center to Center Distance: 107mm
• Inner diameter of the small connecting rod end: 20 mm
• Width of small connecting rod end: 20 mm
• Crank pin length: 61,800 mm

Components of the connecting rod set

• connecting rod
• Crank pin
• crank pin bearing

Vehicle assignment

• SUZUKI DR Z 400 E, built between 2000 and 2015

Note on selection

The motorcycle model and the complete year of manufacture as well as the connecting rod and crank pin dimensions mentioned are decisive for the assignment. The measurement overview makes it possible to compare all relevant diameters, widths and lengths directly before use.
