Piaggio Medley 125 IE S ABS (MA 01) [2016-2018] - H20 I-Tech cylinder set - Ø63mm Piaggio/Vespa

MALOSSI H20 I-Tech cylinder set with Ø 63 mm

The H20 I-Tech cylinder set from MALOSSI combines a bore of Ø 63 mm with a stroke of 58.7 mm. This results in a displacement of 183 cm³. The compression ratio is 11.48. The newly calculated heat exchange surfaces complement the precisely manufactured cylinder-piston connection with 0.05 mm clearance.

Cylinder and machining

• Primary aluminum alloy with high content of hardened and tempered silicon
• Cylinder liner with silicon carbide coating in a galvanic nickel die
• Cross smoothing with two diamond passes and very limited tolerances
• Machining on machine tools with high-precision numerical control

Pistons and piston rings

The ultra-compact, lightweight and reinforced piston has three rings. It consists of a special aluminum alloy with a high silicon content and low thermal expansion. The sliding surfaces have a tin coating. The piston is also machined on numerically controlled machine tools and has improved heat exchange surfaces.

• First ring: compression ring made of nitrided and chrome-plated steel
• Second ring: special cast iron
• Wiper ring: three-piece design made of special chrome-plated steel alloy

Vehicle assignment

The MALOSSI cylinder set is assigned to the Piaggio Medley 125 IE S ABS (MA 01) built between 2016 and 2018.

Factual usage information

This product is intended exclusively for competitions taking place at designated venues and in accordance with the regulations of the relevant sports associations. No liability is assumed for improper use. Product-specific instructions are available as a PDF.
